2000kg Electric Reach Warehouse Forklift Trucks Walking Type 500mm Reach Distance
  • name
  • name

2000kg Electric Reach Warehouse Forklift Trucks Walking Type 500mm Reach Distance

MOQ: 1 set
Price: Negotiable
Standard Packaging: Nude
Delivery Period: 25 - 30 days
Payment Method: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Capacity: 200 sets per month
Detail Information
Product Description
Detail Information
Place of Origin
Zhejiang, China
Brand Name
REACH
Certification
CE, TUV
Model Number
CQDH20A
Capacity:
2000kg
Operation Type:
Walking
Load Center:
500mm
Max. Lifting Height:
2000-5500mm
Fork Dimensions:
40/100/1050mm
Reach Distance:
500mm
Battery:
24V490(525)AH
Service Weight:
2450-2800kg
Highlight:

three wheel electric forklift

,

warehouse lift truck

,

2000kg warehouse forklift trucks

Product Description



2000kg electric reach stacker warehouse forklift trucks fork reach 500mm


Quick Details:

Model: Electric fork reach type warehouse forklift trucks CQDH20A
​​​Capacity: 2000kg
Lift height: 2000-5500mm
Fork dimensions: 40/100/1050mm

​Aisle width for pallets 1000*1200 lengthways: 2828/2850mm

​Aisle width for pallets 800*1200 crossways: 2896/2919mm

​Turning radius: 1879/1899mm
Travel speed, load/unload: 4.8/5km/h​

​Lifting speed, load/unload: 0.095/0.12m/s

​Lowering speed, load/unload: 0.2/0.15m/s​
Reach distance: 500mm

Battery: 24V490(525)Ah​


Advantages:

  • Reach stacker with very compact design, have different option with platform or without platform.
  • Low gravity, ensure safety operation.
  • Water proof and dust proof motor structure, keeps the braking and motor more durable and reliable.
  • Multi function display with BDI, hour meter and fault code.
  • Vertical driving wheel ensures convenient maintenance and small turning radius.
  • The mast and frame are dividable and exchangeable.
  • Advanced AC drive motor eliminates replacement of carbon brush, with good ramp starting performance.
  • Use Germany Frei handle to control driving speed, lifting/lowering speed, side shift, fork reach and tilting.
  • Cylinder have safety explosion proof valve, to avoid fork dropping suddenly when oil tube is broken, ensure the safety of operator.
  • Automatic speed deceleration when lifting height is up to 1.8m.
  • Mast with micro switch limit the cylinder lifting height, avoid mast shock problems.
  • Low voltage protection setting prolongs the battery life. (While battery less than 20%, it can only drive, no lifting).
  • Option EPS power steering system makes steering more light and reliable.



  Magnetic Valve Control



2000kg Electric Reach Warehouse Forklift Trucks Walking Type 500mm Reach Distance 0



SPECIFICATIONS
Model   CQDH20A
Load capacity kg 2000
Load center distance mm 500
Load distance, centre of drive axle to fork mm 265(double mast)/262(triple mast)
Tyre size, front mm 250*82+150*62
Tyre size, rear mm 125*82*4
Fork, tilt forward/backward ° 2/5
Height, mast lowered mm 1625/1875/2125/2375/2625/2185/2345/2505
Free lift (option) mm ~ / ~ / ~ / ~ / ~ /1575/1700/1825
Max. lifting height mm 2000/2500/3000/3500/4000/4500/5000/5500
Height, mast extended mm 2897/3397/3897/4397/4897/5397/5881/6397
Overall length mm 2550/2550/2550/2550/2550/2574/2574/2574
Length to face of forks mm 1480(double mast)/1504(triple mast)
Overall width mm 1200-1300/950
Fork dimensions mm 40/100/1070
Reach distance mm 500
Aisle width for pallets 800*1200 lengthways mm 2996/2996/2996/2996/2996/3019/3019/3019
Turning radius mm 1779/1779/1779/1779/1779/1799/1799/1799
Travel speed, laden/unladen km/h 4.8/5
Lift speed, laden/unladen m/s 0.095(with sideshift)0.08(without sideshift)/0.12
Lowering speed, laden/unladen m/s 0.2/0.15
Battery V/Ah 24/490(525)
Service weight kg 2450/2450/2500/2550/2550/2700/2750/2800



2000kg Electric Reach Warehouse Forklift Trucks Walking Type 500mm Reach Distance 12000kg Electric Reach Warehouse Forklift Trucks Walking Type 500mm Reach Distance 2
