Brief introduction:
＞ Load capacity: 1800kg (1500/2000kg are available)
＞ Max. lifting height: 180mm / 190mm
＞ Height of tiller in drive postion, min./max.: 950mm / 1310mm
＞ Turning radius: 1347mm / 1415mm
＞ Battery voltage, nominal capacity K20: 24V/105Ah
Product specification:
| SPECIFICATIONS | ||
| Model | CBD18W | |
| Load capacity | kg | 1800 |
| Fork height, lowered | mm | 85/75 |
| Tyre size, front | mm | 195*70 |
| Tyre size, rear | mm | 80*70/74*70 |
| Max. lifting height | mm | 190/180 |
| Height of tiller in drive position min./max. | mm | 950/1310 |
| Overall length | mm | 1525/1595 |
| Length to face of forks | mm | 375 |
| Overall width | mm | 685 |
| Fork dimensions | mm | 53/160/1150(1220) |
| Width overall forks | mm | 520/550/685 |
| Aisle width for pallets 1000*1200 crossways | mm | 1725/1795 |
| Aisle width for pallets 800*1200 lengthways | mm | 1775/1795 |
| Turning radius | mm | 1347/1415 |
| Travel speed, laden/unladen | km/h | 4.5/5 |
| Battery | V/Ah | 24/105 |
| Service weight | kg | 250 |
Advantages:
1. CBD18W is workable in narrow aisle, it has same outsize as manual pallet truck which offers samll turning radius.
2. Maintenance free DC brushless motor, high electric efficiency.
3. CBD18W uses full sealed battery which is free to maintain, battery capacity 105Ah fit for high intensity use.
4. The max. speed limit button can release brake when handle in a upright condition which reduce turning space greatly.
5. 5.3-5.8km/h high moving speed, which improves productive efficiency greatly.
6. Floating balance wheel can adjusts height automatically, it will prevents shaking when there is nothing on the pallet.
7. Horizontal drive wheel is very convenient when replacement.
... ...
