Quick details:
＞ Load capacity: 1200kg (1500kg is available)
＞ Max. lifting height: 110mm
＞ Height of tiller in drive postion, min./max.: 635mm/1200mm
＞ Turning radius: 1452mm/1522mm
＞ Charging time: 3 hours
＞ Working time: 6 hours
＞ Work shift: 24 hours
＞ Range of application: Indoor use, light duty work, warehouses freight handling, frozen food storage, chemical handling and processing facilities, etc...
Product specification:
| SPECIFICATIONS | ||
| Model | CBD12W | |
| Load capacity | kg | 1200 |
| Load centre distance | mm | 600 |
| Fork height, lowered | mm | 80 |
| Tyre size, front | mm | 250 |
| Tyre size, rear | mm | 80 |
| Max. lifting height | mm | 190 |
| Height of tiller in drive position min./max. | mm | 635/1200 |
| Overall length | mm | 1651/1721 |
| Length to face of forks | mm | 501 |
| Overall width | mm | 550/680 |
| Fork dimensions | mm | 45/160/1150(1220) |
| Width overall forks | mm | 550/680 |
| Aisle width for pallets 1000*1200 crossways | mm | 1850/1920 |
| Aisle width for pallets 800*1200 lengthways | mm | 1900/1920 |
| Turning radius | mm | 1452/1522 |
| Travel speed, laden/unladen | km/h | 4/4.5 |
| Battery | V/Ah | 48/20 |
| Service weight | kg | 140 |
Advantages:
1. Using 48V maintenance-free lithium battery, it can works around 6 hours.
2. Only need 3 hours can be fully charged.
3. The Lithium battery is very light, even a little girl can picks it up. The battery can be replaced in 10 seconds.
4. CBD12W can be used for 24 hours of continuous work, use two groups exchanged battery, one charging, one using.
5. CBD12W uses brushless motor which offers high efficiency and no need to maintain.
6. Stepless speed, smooth speed changing,
7. CBD12W has beautiful appearance and light weight, flexible steering which can enter the narrow space successfully, such as elevators, small super market.
8. Less wire, easy service. Mechanical and electronic components are easy to change and service.
9. CBD12W uses long tiller with large hand grip, for easy and comfortable hold, strain-free operation.
... ...
