Quick details:
＞ Load capacity options: 1000kg / 1500kg / 2000kg
＞ Max. lifting height: 1600mm / 2500mm / 3000mm / 3300mm / 3500mm
＞ Fork length: 1150mm
＞ Lift speed, laden/ unladen: 0.135/0.15 m/s
＞ Aisle width: 2368mm
Product specification:
| SPECIFICATIONS | ||
| Model | BDA | |
| Driving style | Manual | |
| Load capacity | kg | 1000/ 1500/ 2000 |
| Load center distance | mm | 500 |
| Wheel | mm | Nylon/PU |
| Tyre size, front | mm | 180*50 |
| Tyre size, rear | mm | 80*70 |
| Lowered mast height | mm | 2085/ 1585/ 1835/ 2085/ 2235/ 2335 |
| Max. lifting height | mm | 1600/ 2000/ 2500/ 3000/ 3300/ 3500 |
| Extended mast height | mm | 2083/ 2550/ 3050/ 3550/ 3850/ 4050 |
| Lowered fork height | mm | 90 |
| Overall length | mm | 1735 |
| Overall width | mm | 800 |
| Fork length | mm | 900/1070 |
| Width overall forks | mm | 660 |
| Ground clearance | mm | 26 |
| Aisle width for pallets 1000*1200 crossways | mm | 1705 |
| Aisle width for pallets 800*1200 lengthways | mm | 1755 |
| Turning radius | mm | 1415 |
| Lift speed, laden/unladen | m/s | 0.135/0.15 |
| Lowering speed, laden/unladen | m/s | manual control |
| Battery | V/Ah | 12/1 |
| Service weight | kg | 380/450/480 |
Advantages:
1) Strong mast material ensure high capacity.
2) Explosion-proof value in the pump, to avoid rapid decline to ensure the operator's safety.
3) Over-discharge protection device greatly extends battery life.
4) Foot brake is simple and easy to maintain.
...
