Big Capacity Ride On Pallet Truck , Heavy Duty Narrow Pallet Jack Lightweight
6 sets
MOQ
Negotiable
Price
Big Capacity Ride On Pallet Truck , Heavy Duty Narrow Pallet Jack Lightweight
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: Zhejiang, China
Brand Name: REACH
Certification: CE, TUV
Model Number: WB
High Light:

low profile pallet jack

,

mobile pallet truck

Payment & Shipping Terms
Packaging Details: 6sets/pallet, 144 / 180sets for a 20ft container
Delivery Time: 25 - 30 days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 40000 sets per month
Specifications
Capacity: 5000kg
Lowered Fork Height: 88/78mm
Steering Wheel: 200/180
Fork Wheel: 85*80/75*80
Max. Lifting Height: 205/195mm
Fork Length: 1150/1220mm
Width Overall Forks: 550/685mm
Service Weight: 103-110kg
Product Description



Big capacity 5000kg hand pallet truck high reliability and long service life of 5 years



Quick Details



Model: heavy duty type hand pallet truck

​​​Capacity: 5000kg

Lowered fork height: 88/78mm

Total lift height: 205/195mm

Fork dimension: 550/685*1150/1220mm





Advantages:

  • High reliability and long service life of 5 years.
  • Double lifting speed when loads under 600kg, which turns back to regular speed when above it.
  • Impact free lifting ensures safety of cargo loading.
  • The lifting system is equipped with overloading protection valve to ensure the safe operation.
  • The utilized structural design guarantees the convenience of assembling and disassembling.
  • Light-weight fork frame, made from high rigidity steel plate.
  • Compact appeatance, complete rocker arm, ensure the whole truck evenly pressed.
  • There is a finger hole in the connection of handle and pump, easy to assemble.



Big Capacity Ride On Pallet Truck , Heavy Duty Narrow Pallet Jack Lightweight 0

SPECIFICATIONS
Model   WB
Load capacity kg 5000
Lowered fork height mm 88/78
Steering wheel mm 200/180
Fork wheel single mm ~
Fork wheel tandem mm 85*80/75*80
Max. lifting height mm 205/195
Total height mm 1253/1243
Overall length mm 1544/1614
Fork length mm 1150/1220
Width overall forks mm 550/685
Ground clearance, centre of wheelbase mm 28/18
Aisle width for pallets 1000*1200 crossways mm 1744/1814
Aisle width for pallets 800*1200 lengthways mm 1794/1814
Turning radius mm 1300/1370
Service weight kg 103-110
